For-A HVS-2000 (Used)

3G/HD/SD Two-M/E Video Switcher

The HVS-2000 allows for easy control of multi-screen staging with independent transitions, keys, and graphics on each display. A special mode called ONStage allows grouping multiple mix effects, which can then be controlled with one fader lever. Therefore, with one pull you can transition multiple monitors with different information. Up to 900 frames of images can be stored in a hard drive, and more can be brought into the system via a USB flash drive. Also, your configuration of the switcher can be stored in a USB flash drive so you can instantly restore your settings at any time.

-Two M/E plus four MELite with FLEXaKEY architecture for six-M/E capability.
-Expandable to three M/E plus four MELite with FLEXaKEY.
-24 inputs and 18 outputs including 2 HDMI.
-Expandable to up to 48 inputs and 18 outputs, or 40 inputs and 22 outputs.
-Six I/O expansion slots for installing HVS-100 series cards (available separately).
-PGM, PVW, and two Clean outputs per full M/E.
-Supports 4K input in 2SI format via separately available software.
-Multi-format HD/SD/HDMI/analog/VGA via expansion cards (available separately).
-3G/4K-ready via optional software.
-Four keyers per M/E, and four FLEXaKEYs (assignable to M/E or AUX).
-Up to six keyers can be assigned to M/E 1, up to eight to M/E 2, and up to four to AUX.
-Eight 2.5D DVEs.
-Four 3D DVEs for use in 4K video processing via expansion card (available separately).
-18 auxiliary buses (2 HDMI, 12 SDI, 8 AUX transition, 6 MELite function).
-HVS-2000GUI intuitive GUI software included for easy configuration.
-Control panel with LED, RGB, user-configurable color buttons, and 7" touch mini menu GUI.
-Two-channel multiviewer, expandable to four channels and 64 windows via expansion card (available separately).
-All inputs have FS with still image store and capture.
-Four dedicated still/clip stores installed with 900 frames at 1080 resolution, approx. 30 seconds at 1080i (expansion cards available separately).
-All full M/E keyers have chroma keys, and support two additional channels of advanced chroma keys (expansion card available separately).
-Easy operation with Midas Touch master setup and configuration GUI.
-ONStage mode for stage and multi-screen applications.
-Color corrector input, output, and bus lines via expansion cards (available separately).
