DPA Microphones 4080-DC-D-B00 (New)
Price via quote
discreet CORE 4080 Cardioid Microphone-Normal SPL-Black-MicroDot
Select Condition
DPA Microphones 4080-DC-D-B00 (New)
discreet CORE 4080 Cardioid Microphone-Normal SPL-Black-MicroDot
While DPA's 4080-DC-D-B00 miniature omnidirectional mics are ideal for situations where a broad pickup pattern is essential and off-axis noise is not a problem, in some challenging acoustic environments a directional microphone is the better choice. The 4080 Cardioid Lavalier captures the human voice with an unusually high degree of definition. This mic offers maximum side rejection and excellent sonic focus on the subject. It is designed for broadcast, conference and other live performances both in the studio and in the field.
Features
Excellent speech reproduction
Discreet, compact design
Fits both left and right buttoned shirts
Delivered with both black and white pop filters
Modular adapter system fits most professional wireless systems
Directional Pattern: Cardioid
Principle of Operation: Pressure gradient
Cartridge Type: Pre-polarized condenser
Frequency Response: 20 Hz - 20 kHz
Effective Frequency Range ±2 dB: 250 Hz - 17 kHz with typ. 4 dB soft boost at 4 - 6 kHz (-5 dB at 100 Hz)
Sensitivity, Nominal, ±3 dB at 1 kHz: 20 mV/Pa; -34 dB re. 1 V/Pa
Equivalent Noise Level, A-Weighted: Typ. 23 dB(A) re. 20 æPa (max. 26 dB(A))
Distortion, THD < 1% - Legacy: 120 dB SPL RMS, 123 dB SPL peak
Distortion, THD < 1% - CORE: 126 dB SPL RMS, 129 dB SPL peak
Dynamic Range: Typ. 100 dB
Max. SPL, THD 10%: 134 dB SPL peak
Rated Output Impedance: 30 - 40 Ω
Cable Drive Capability: Up to 300m (984') with DAD6001-BC XLR Adapter
Power Supply (for Full Performance): Min. 5 V - max. 50 V through DPA adapter for wireless systems or 48 V phantom power ±4 V with DAD6001-BC XLR adapter
Connector: MicroDot
Color: Black
Weight: 15g (0.5oz) incl. Cable and MicroDot connector
Microphone Diameter: 10mm (0.4")
Capsule Diameter: 5.4mm (0.21")
Microphone Length: 30mm (1.2")
Cable Length: 1.2m (3.9')
Cable Color: Black
Cable Diameter: 1.6mm (0.06")
Polarity: Positively increasing sound pressure produces positive going voltage on MicroDot pin
Temperature Range: -40°C to 45°C (-40°F to 113°F)
Relative Humidity (RH): Up to 90%
